rtemis: Advanced Machine Learning & Visualization.

This is the new version of the rtemis R package and remains under active development.

The new version (0.99+) features:

• Backend: complete rewrite of the supervised and unsupervised learning backend using the new S7 class system, replacing all previous use of R6 and S3 classes.
• API: Functional user-facing API, to maintain a consistent, user-friendly interface.
• Extended use of setup_() functions, to offer increased transparency of configuration options.
• Strict type checking and condition validation throughout to minimize user error and provide highly focused error messages & suggestions.
• Expanded transparent messaging through each step.

Installation of rtemis

Using pak from GitHub:

pak::pkg_install("rtemis-org/rtemis")

Using install.packages from r-universe:

install.packages(
  'rtemis',
  repos = c('https://egenn.r-universe.dev', 'https://cloud.r-project.org')
)

Using pak from r-universe:

pak::repo_add(myuniverse = "https://egenn.r-universe.dev")
pak::pkg_install("rtemis")

Installation of dependencies

Every rtemis call that uses external packages includes a check for required dependencies and will print a message if any are missing.

Transparent messaging

It is essential to maintain transparency of operations at all times. rtemis functions often call multiple other functions, sometime recursively. The package uses a formatted messaging system to provide logging output which includes:

• Timestamp
• Message
• Origin (function name)

Most function include a verbosity argument to control the level of messaging output, with support for three levels:

• 0: silent
• 1: normal messaging
• 2: detailed messaging for debugging

Text formatting

rtemis includes an automatic text formatting system, which supports:

• plain text output (for output to log files)
• ANSI colored output (for R console)
• HTML formatted output (for Quarto documents, shiny apps, etc.)

setup_ functions

Machine learning workflows involve multiple steps, each with their own configuration options.

It is essential that a) the user has complete control over each step, while maintaining an intuitive, user-friendly interface, and b) the user input is validated immediately and before a potentially long-running operation is started.

The following setup_ functions are available to configure each step of the workflow:

• Supervised Learning: setup_CART(), setup_GAM(), etc.
• Tuning: setup_GridSearch()
• Clustering: setup_CMeans(), setup_HardCL(), etc.
• Decomposition: setup_NMF(), setup_ICA(), etc.
• Resampling: setup_Resampler()
• Preprocessing: setup_Preprocessor()

Supervised Learning

The following will perform hyperparameter tuning and 10-fold cross-validation.
It will train (3*3*2*5 + 1) * 25 = 2275 models total (!).

mod <- train(
  dat,
  hyperparameters = setup_LightGBM(
        num_leaves = 2^(1:3),
        learning_rate = c(.001, .005, .01),
        subsample = c(.6, .9)
  ),
  outer_resampling_config = setup_Resampler(
    n_resamples = 25L,
    type = "StratSub"
  )
)

Clustering

clust <- cluster(
  dat,
  config = setup_CMeans(k = 4L)
)

Decomposition

decomp <- decompose(
  dat,
  config = setup_ICA(k = 12L)
)

Changes from original implementation & Ongoing work

Algorithms

The original version included a long list of algorithms for supervised and unsupervised learning for testing and experimentation, many of which were rarely used. The initial release of the new version focuses on a smaller set of core algorithms, that will keep growing.

Visualization

The original version included the mplot3 family of visualization functions using base R graphics and the dplot3 family using plotly. The new release includes the draw family of functions, the evolution of the dplot3 family.

Documentation

The documentation is available at rdocs.rtemis.org, which includes walkthroughs of main features and full API reference.

rtemisalpha

The original, unmaintained version of rtemis remains available as rtemisalpha here.
