Weather Station Platform

This repository holds the infrastructure the rest of the Weather Station system depends on. It carries no application code: the firmware, the backend, and the frontend live in their own repositories and connect to what is defined here.

Directory	Purpose
compose/	The Docker Compose files: the local development stack and the whole production stack
terraform/	Azure resources that host the system: VM, network, container registry and Key Vault
ansible/	Packages installed on that VM, and the production stack it runs
scripts/	Operator scripts that write the broker certificate and passwords to Key Vault
edge/	Nginx in front of the frontend and backend: TLS and routing

The two halves are independent. compose/ is what you run for local development; terraform/ provisions the machine where that same stack runs in production, and ansible/ installs what that machine needs to run it. edge/ runs only in production, on that machine.

Services

Service	Image	Port	Role
mosquitto	eclipse-mosquitto:2.1-alpine	1883, and 8883 with TLS in production	Receives the sensor readings published by the ESP32 boards
influxdb3	influxdb:3-core	8181	Stores the snapshots written by the backend
influxdb-init	curlimages/curl:8.12.1	—	Creates the configured InfluxDB database once, then exits
backend	Local build or versioned production image	8000	Stores snapshots and serves live and historical readings

The backend sits between Mosquitto and InfluxDB: it subscribes to the broker, assembles complete snapshots and writes them to InfluxDB. The initializer configures the database before the backend starts; it exits with status 0 after setup, which is expected. compose/init-influxdb.sh runs inside a Linux container and is kept in LF format by .gitattributes, including when checked out on Windows.

Local development

Requirements

Docker Engine with the Compose v2 plugin and a sibling checkout of weather-station-backend, because the local backend image is built from source. For example, the two repositories should be next to each other:

projects/
  weather-station-platform/
  weather-station-backend/

Mosquitto and InfluxDB run from their official images; Compose builds the backend from the sibling checkout.

Configuration

The local stack reads the variables in compose/.env.example:

cp compose/.env.example compose/.env

Variable	Default	Purpose
MQTT_PORT	1999	Host port mapped to the Mosquitto broker
INFLUXDB_PORT	2000	Reserved; the Compose file currently publishes InfluxDB on 8181 directly, so this value has no effect
INFLUXDB_DATABASE	weather-station-db	Database created by the InfluxDB initializer and used by the backend
INFLUXDB_RETENTION_PERIOD	15d	Retention period applied when the database is first created
INFLUXDB_QUERY_FILE_LIMIT	600	InfluxDB server-wide maximum Parquet files accessed by a query
HISTORICAL_CACHE_RETENTION_DAYS	15	Maximum age of cached historical day segments; keep aligned with InfluxDB retention

The file must sit next to docker-compose.yaml, inside compose/. Docker Compose resolves .env from the project directory — the directory holding the compose file — not from the directory the command runs in. A .env placed in the repository root is never read.

That failure is silent. An unset MQTT_PORT expands to an empty string, and Docker answers an empty host port by publishing the broker on a random one, so the stack reports itself as running while the ESP32 boards cannot reach it. Confirm the mapping instead of assuming it:

docker compose -f compose/docker-compose.yaml config | grep -A2 'target: 1883'

Passing the file explicitly with --env-file <path> also works and ignores the project directory entirely.

Start

docker compose -f compose/docker-compose.yaml up -d --build

Verify

docker compose -f compose/docker-compose.yaml ps        # initializer Exited (0) is expected
docker port mosquitto                                     # must read 1883 -> 0.0.0.0:1883
curl http://localhost:8181/health                        # InfluxDB answering: OK
curl "http://localhost:8000/api/v1/readings/station-01?from=2026-09-01T00:00:00Z&to=2026-09-03T00:00:00Z"
docker run --rm --network host eclipse-mosquitto:2.1-alpine \
    mosquitto_sub -h 127.0.0.1 -t 'weather/#' -v         # live readings

The backend caches completed UTC days in SQLite at /var/lib/weather-cache/historical.sqlite3; requests touching the current UTC day still query InfluxDB. The dedicated historical-cache Docker volume survives backend container restarts and docker compose down. To inspect its entries while the backend is running:

docker compose -f compose/docker-compose.yaml exec backend \
    python -c 'import sqlite3; c=sqlite3.connect("/var/lib/weather-cache/historical.sqlite3"); print(c.execute("SELECT station_id, utc_date FROM historical_days ORDER BY utc_date").fetchall())'
docker compose -f compose/docker-compose.yaml restart backend

docker compose down -v also deletes the cache. When changing INFLUXDB_RETENTION_PERIOD, set HISTORICAL_CACHE_RETENTION_DAYS to the same number of days so cached data does not outlive its source retention.

Stop

docker compose -f compose/docker-compose.yaml down       # keeps local data
docker compose -f compose/docker-compose.yaml down -v    # also removes named volumes

Mosquitto and InfluxDB store runtime data in bind-mounted directories under compose/. These directories survive both commands above; down -v removes Docker-managed named volumes (including the historical cache), not bind-mounted host directories.

MQTT broker

The broker is configured by compose/mosquitto/config/mosquitto.conf:

listener 1883 0.0.0.0

allow_anonymous true

persistence true
persistence_location /mosquitto/data/

log_dest stdout

The explicit listener matters. Mosquitto 2.0 and later accept only local connections under their built-in defaults, so without this line the ESP32 boards would be refused.

Persistence writes retained messages and queued QoS messages to compose/mosquitto/data/, so they survive container restarts and removal. The directory is local runtime data and is excluded from Git. Logs go to stdout, where the Docker logging driver collects them:

docker compose -f compose/docker-compose.yaml logs -f mosquitto

The firmware publishes one topic per measurement:

weather/<device-id>/airTemperature
weather/<device-id>/airPressure
weather/<device-id>/airHumidity
weather/<device-id>/daylight
weather/<device-id>/waterLevel
weather/<device-id>/airQuality

In secrets.h, the ESP32 must point at the LAN address of the machine running this stack — never localhost, which from the board means the board itself.

Authentication is disabled in development. allow_anonymous true lets any client on the network publish and subscribe, which is acceptable on a development LAN and not on a public address. Production uses its own configuration, described below.

Production broker

The VM runs compose/mosquitto/config/mosquitto.prod.conf, installed as mosquitto.conf, with two listeners:

Listener	Reachable from	Transport	Clients
8883	Internet, published by Compose	TLS	The ESP32 boards
1883	The Compose network only, never published	Plain TCP	The backend

Both listeners require a username and password: allow_anonymous false applies to every listener. The password file is generated on the VM from Key Vault on each deployment; see Secrets.

compose/mosquitto/config/aclfile decides what each user may do:

Rule	Effect
pattern write weather/%u/+	Each station publishes only under its own username: station-01 writes weather/station-01/airTemperature and cannot write weather/station-02/...
user weather-station-backend + topic read weather/+/+	Only the backend subscribes to the readings

A station's MQTT username is its DEVICE_ID. Adding a station means adding its ID to weather_platform_mqtt_station_ids in the weather-platform role defaults and creating its password.

InfluxDB

The service runs InfluxDB 3 Core with authorization turned off:

--node-id influxdb3
--object-store file
--data-dir /var/lib/influxdb3
--without-auth

Data is stored in the bind-mounted directory compose/influxdb3-data/ on the host, mapped to /var/lib/influxdb3 in the container. The directory is excluded from Git and survives container restarts, docker compose down, and docker compose down -v; remove it from the host only when you intend to delete the local database data.

The influxdb-init one-shot service creates the configured database through the InfluxDB API before the production backend starts. In local development, docker compose up runs the same initializer. It sets a 15-day data retention period by default; points older than 15 days expire under this policy. If the database already exists, the initializer accepts the conflict and leaves it unchanged. Changing retention on an existing database requires a separate migration.

The server's Parquet file-access limit is 600 files per query by default (InfluxDB 3 Core's default is 432). This is a server-wide startup setting, not a per-database property. A higher limit can increase query latency and memory use. Adjust INFLUXDB_QUERY_FILE_LIMIT cautiously and recreate/restart InfluxDB for the setting to take effect.

Local settings live in compose/.env:

INFLUXDB_DATABASE=weather-station-db
INFLUXDB_RETENTION_PERIOD=15d
INFLUXDB_QUERY_FILE_LIMIT=600

Copy compose/.env.example to create the local file. Production values are managed by the weather-platform Ansible role defaults. The backend receives the configured database name from Compose and no longer creates or configures the database itself.

Write and read a point by hand:

curl -X POST "http://localhost:8181/api/v3/write_lp?db=weather-station-db" \
    --data-binary 'weather_reading,station_id=station-01 temperature=21.5'

curl -X POST "http://localhost:8181/api/v3/query_sql" \
    -H 'Content-Type: application/json' \
    -d '{"db":"weather-station-db","q":"SELECT * FROM weather_reading LIMIT 5"}'

Infrastructure

The terraform/ module provisions the Azure host in mexicocentral. The Azure for Students subscription only allows deployments in a fixed list of regions (az policy assignment list), and none of them is in Brazil; Mexico Central is the closest. It requires Terraform 1.9 or later (1.x) and the azurerm provider 5.5 or later (5.x).

Resources

Resource	Name	Notes
Resource group	weather-station-rg	Holds everything below
Container registry	var.acr_name	Basic, globally unique; admin account disabled
Virtual network	weather-station-vnet	10.10.0.0/16
Subnet	weather-station-subnet	10.10.1.0/24
Network security group	weather-station-nsg	Rules below
Public IP	weather-station-pip	Standard SKU, static, with a DNS label
Network interface	weather-station-nic
Virtual machine	weather-station-vm	Ubuntu 24.04 LTS, Standard_B2ats_v2, 30 GB disk
Role assignment	—	Grants the VM AcrPull on the registry
Key Vault	var.key_vault_name	Standard, globally unique, RBAC authorization, reachable only from the VM's public IP and ssh_allowed_cidrs
Role assignment		Grants the VM Key Vault Secrets User on the vault: it reads the broker secrets
Role assignment		Grants the operator running apply Key Vault Secrets Officer on the vault: it writes them

The VM carries a system-assigned managed identity, and that identity is what holds AcrPull. The registry needs no stored credentials: the VM pulls images using its own identity, and admin_enabled = false keeps the registry's shared account switched off.

Password authentication is disabled on the VM. Access is by SSH key only, taken from ssh_public_key. The key is set by value, not read from a local path, so every operator plans against the same key — a different key would force the VM to be replaced.

The VM has prevent_destroy. Its OS disk holds the InfluxDB data, the broker state and the ACME certificate, so any plan that would destroy or replace it fails instead. Remove the lifecycle block deliberately if that is really intended.

Firewall

Port	Priority	Source	Purpose
22	100	ssh_allowed_cidrs — no default	Administrative access
80, 443	110	Internet	Frontend, backend API over TLS and ACME HTTP-01
8883	120	Internet	MQTT over TLS from the ESP32 boards (dynamic addresses)

ssh_allowed_cidrs must be set — the module refuses an empty list and 0.0.0.0/0. Use your own address with a /32 mask; get it with curl -4 -s ifconfig.me. The same list opens the Key Vault firewall, so when your address changes, update it and run apply again before using the scripts in Secrets.

State

State is stored in an Azure Storage Account, declared in the backend block of versions.tf. The blob lease locks the state during every operation, and access uses Entra ID (use_azuread_auth), so the account keeps shared keys disabled.

The account is created once, outside Terraform, because it must exist before init. Its name is globally unique: if weatherstationtfstate is taken, pick another and update storage_account_name in versions.tf.

az provider register --namespace Microsoft.Storage --wait

az group create -n weather-station-tfstate-rg -l mexicocentral

az storage account create -n weatherstationtfstate -g weather-station-tfstate-rg \
    -l mexicocentral --sku Standard_LRS --min-tls-version TLS1_2 \
    --allow-blob-public-access false --allow-shared-key-access false

az storage account blob-service-properties update \
    --account-name weatherstationtfstate -g weather-station-tfstate-rg \
    --enable-versioning true --enable-delete-retention true --delete-retention-days 30

az role assignment create --role "Storage Blob Data Contributor" \
    --assignee "$(az ad signed-in-user show --query id -o tsv)" \
    --scope "$(az storage account show -n weatherstationtfstate -g weather-station-tfstate-rg --query id -o tsv)"

az storage container create -n tfstate --account-name weatherstationtfstate --auth-mode login

The first command registers the storage resource provider: new subscriptions, such as Azure for Students, start without it, and every other command fails with SubscriptionNotFound until it is registered.

Blob versioning keeps every previous state, so a corrupted or overwritten state can be restored. The role assignment may take a minute to propagate. Every other operator needs the same Storage Blob Data Contributor role on the account.

Usage

az login
cp terraform/terraform.tfvars.example terraform/terraform.tfvars

Fill in subscription_id, ssh_allowed_cidrs, ssh_public_key, dns_label, acr_name and key_vault_name. The example file carries the command for each value. Then:

terraform -chdir=terraform init
terraform -chdir=terraform plan -out=main.tfplan
terraform -chdir=terraform apply main.tfplan

terraform.tfvars is ignored by Git and must not be committed.

Outputs

terraform -chdir=terraform output

Output	Used for
public_ip_address	The target of the A record of the project domain; see Domain
public_fqdn	<dns_label>.mexicocentral.cloudapp.azure.com, the name Azure generates; a second name in the broker certificate
acr_login_server	Registry hostname used in image tags
acr_name	az acr login --name <value>
key_vault_name	The scripts in Secrets and weather_platform_key_vault_name in the weather-platform role
resource_group_name	Scoping az commands
vm_name	Scoping az commands

Domain

The system answers on weather-station.thomaspalma.com.br: the website, the API under /api/ and the MQTT broker on port 8883 all use that name. It is a subdomain of thomaspalma.com.br, whose DNS is hosted by Registro.br, so the record is created by hand in the Registro.br panel, not by Terraform:

Name	Type	Value
weather-station	A	The public_ip_address output

The public IP is static, and deallocating the VM keeps it, so the record only changes if the public IP resource is destroyed and created again. Check the record from the operator workstation:

dig +short A weather-station.thomaspalma.com.br

The answer must be the public_ip_address output. The same name appears in server_name in edge/nginx.conf, in ansible_host in ansible/inventory/azure.yaml, in the broker certificate, in MQTT_HOSTS in the firmware and in the PUBLIC_FQDN variable of the backend and frontend repositories.

What is not automated

Terraform provisions the host and nothing more. Everything above it comes from ansible/: the packages, the production stack and each release. See Host configuration.

Secrets

The broker secrets live in the Key Vault created by terraform/. Their values never enter Terraform or Git: the operator writes them with the two scripts below, and the weather-platform role reads them on the VM with the managed identity, the same way it signs in to the registry.

Secret	Written by	Read by
mqtt-server-certificate	scripts/issue-mqtt-certificate.sh	Mosquitto, as certs/server.crt
mqtt-server-private-key	scripts/issue-mqtt-certificate.sh	Mosquitto, as certs/server.key
mqtt-password-<username>	scripts/create-mqtt-password.sh	Mosquitto's password file, the backend's .env and, for stations, secrets.h in the firmware

Both scripts run on the operator workstation, after terraform apply, with az login done and your address in ssh_allowed_cidrs. The Key Vault Secrets Officer role may take a few minutes to propagate after the first apply.

Broker certificate

The broker uses a certificate signed by a private Certificate Authority (CA). The firmware trusts that CA directly, so the certificate does not depend on Let's Encrypt or on the edge proxy. On the operator workstation, from the repository root:

scripts/issue-mqtt-certificate.sh "$(terraform -chdir=terraform output -raw key_vault_name)" \
    weather-station.thomaspalma.com.br \
    "$(terraform -chdir=terraform output -raw public_fqdn)"

The script creates the CA in certificates/ on the first run only, issues a new server certificate for every hostname passed, and stores the certificate and its key in Key Vault. certificates/ is ignored by Git.

Keep certificates/ca.key safe and backed up. Running the script again reuses it, so the stations keep trusting the new server certificate. Losing it means creating a new CA and flashing every station again with the new ca.crt.

Broker passwords

One password per MQTT user: each station, by its DEVICE_ID, and the backend. On the operator workstation, from the repository root:

key_vault_name="$(terraform -chdir=terraform output -raw key_vault_name)"
scripts/create-mqtt-password.sh "$key_vault_name" weather-station-backend
scripts/create-mqtt-password.sh "$key_vault_name" station-01

Each run generates a new password, stores it and prints it. Copy the station's password into MQTT_PASSWORD in the firmware's secrets.h; the backend's needs no copy, because Ansible writes it to .env. Passwords are hexadecimal, so they need no quoting in .env or in C strings.

Rotating a password is the same command followed by deploy.yaml, plus a new firmware upload for a station.

Host configuration

ansible/ prepares the VM created by terraform/. configure.yaml installs packages; deploy.yaml copies the production files and starts the stack.

Role	What it does
update-os	Upgrades every package, removes orphans and cleans the apt cache
base-packages	Installs git, curl, jq and other utilities, and sets the timezone
docker-install	Installs Docker Engine with Compose v2 and Buildx from Docker's repository, rotates container logs and adds azureuser to the docker group
azure-cli	Installs the Azure CLI from Microsoft's repository
weather-platform	Installs the production stack and starts it — run by deploy.yaml, not by configure.yaml

The Azure CLI is what lets the VM pull from the registry with its managed identity, without any stored password:

az login --identity
az acr login --name <acr_name>

The registry token lasts about 3 hours. Log in again before each deployment; containers that are already running are not affected.

Usage

It requires ansible-core 2.15 or later. SSH reaches the VM only from ssh_allowed_cidrs, as azureuser, with the key set in ssh_public_key.

ansible_host in ansible/inventory/azure.yaml is the project domain, so its A record must already exist; see Domain. Then:

cd ansible
ansible-galaxy collection install -r requirements.yaml
ansible-playbook playbooks/configure.yaml

Run the commands from ansible/: Ansible reads ansible.cfg from the current directory, and that file points at the inventory and the roles.

The first connection records the VM's host key in ~/.ssh/known_hosts. A different key later stops the run. That is expected only if the VM was replaced: then remove the old entry with ssh-keygen -R weather-station.thomaspalma.com.br.

The VM reboots on its own when an upgrade needs it, for example after a new kernel, and only then: the role checks for /var/run/reboot-required first. Set update_os_reboot_if_required to false in the role's defaults to keep the reboot manual.

Deployment

playbooks/deploy.yaml runs the weather-platform role, which puts the whole stack in /opt/weather-station/ on the VM:

File	Contents
docker-compose.yaml	Copied from compose/docker-compose.prod.yaml: the six services
.env	The registry and application image versions, the InfluxDB settings and the backend's broker credentials; readable by root only
init-influxdb.sh	Copied from compose/; creates the database on startup, then the influxdb-init service exits
nginx.conf	Copied from edge/
mosquitto/config/mosquitto.conf	Copied from compose/mosquitto/config/mosquitto.prod.conf
mosquitto/config/aclfile	Copied from compose/mosquitto/config/
mosquitto/config/passwordfile	Generated from the Key Vault passwords and hashed with mosquitto_passwd
mosquitto/config/certs/	The broker certificate and key, from Key Vault
deploy.sh	Puts one new version in production

Every file is copied as it is in this repository, and the role renders no templates, so what you read here is what runs on the VM. The only generated files are the secrets above. The two application images are named by version, never latest:

image: ${ACR_LOGIN_SERVER}/weather-station-backend:${BACKEND_VERSION:?}

The :? makes Docker Compose refuse to start when the variable is missing, instead of quietly falling back to latest.

The first run needs the broker certificate and every password already in Key Vault (see Secrets), and both versions already published to the registry:

ansible-playbook playbooks/deploy.yaml \
    -e weather_platform_backend_version=1.0.0 \
    -e weather_platform_frontend_version=1.0.0

After that, the pipelines own the backend and frontend version lines in .env; Ansible leaves those unchanged. The role reconciles INFLUXDB_DATABASE, INFLUXDB_RETENTION_PERIOD, INFLUXDB_QUERY_FILE_LIMIT, HISTORICAL_CACHE_RETENTION_DAYS and the backend's MQTT_BACKEND_USERNAME and MQTT_BACKEND_PASSWORD on every deployment.

The password file is regenerated only when a password changes: the role keeps a SHA-256 digest of the credentials next to it and compares it on each run. A new certificate, password or ACL restarts only Mosquitto; the ESP32 boards reconnect on their own within seconds.

Releases

deploy.sh is what the application pipelines call, through az vm run-command, so the VM needs no inbound SSH for a release:

/opt/weather-station/deploy.sh backend 1.0.2

It rewrites that version in .env, signs in to the registry with the VM's managed identity, pulls the image and recreates only that service. It builds nothing: the image must already exist in the registry.

Each application is released on its own, by tagging its repository. To roll back, run the script with the previous version — the image is still in the registry, so nothing is rebuilt.

Edge proxy

edge/nginx.conf is the only public entry to the web application. It answers on ports 80 and 443, obtains and renews the Let's Encrypt certificate by itself, and routes each request:

Path	Destination	Container
/api/	127.0.0.1:8000	backend
everything else	127.0.0.1:8080	frontend

The frontend and the backend are published on 127.0.0.1 only, as their own READMEs describe, so they are reachable only through the edge. FastAPI's /docs and /openapi.json are not exposed: only /api/ reaches the backend.

It does not run locally. Let's Encrypt must reach a public domain on port 80, which only the VM has.

Before starting

• server_name in edge/nginx.conf is the project domain, weather-station.thomaspalma.com.br, and its A record must already resolve to the VM: Let's Encrypt validates the name over port 80 before issuing the certificate. See Domain.
• Build the frontend without VITE_WEATHER_API_URL. Its empty default leaves the API calls relative, so they resolve against the page's own origin — which the edge serves. The same image then works behind any domain, and WEATHER_ALLOWED_ORIGINS can stay empty.
• The production Compose file sets FORWARDED_ALLOW_IPS: "*". Without it, the server ignores the X-Forwarded-* headers the edge sends, because requests arrive from the Docker bridge, not from 127.0.0.1. Trusting every address is safe only because the backend port is bound to 127.0.0.1.

Start

The edge is one of the services in the production stack, so deploy.yaml starts it along with the rest. Its two settings that matter are already in the compose file:

• network_mode: host lets it reach 127.0.0.1:8000 and 127.0.0.1:8080 and listen on ports 80 and 443 of the VM directly.
• The edge-acme volume must be kept. It stores the ACME account, the certificate and its private key. Without it, every restart requests a new certificate, and Let's Encrypt allows only 5 identical certificates per week. docker compose down -v deletes it.

On the first deployment, point uri in edge/nginx.conf at the staging directory, https://acme-staging-v02.api.letsencrypt.org/directory, and switch back to production once the certificate is issued. Delete the edge-acme volume when switching, so the staging account and certificate are discarded.

Verify

curl -I http://weather-station.thomaspalma.com.br                                    # 301 to https
curl https://weather-station.thomaspalma.com.br/healthz                              # ok, from the frontend
curl -N https://weather-station.thomaspalma.com.br/api/v1/readings/station-01/stream # live readings
docker logs edge                                                                     # access log, real client addresses

Security

The production broker is closed: port 8883 is open to the internet, because the ESP32 boards connect from dynamic addresses, but every client needs TLS, a password and an ACL entry. See Production broker.

The development broker keeps allow_anonymous true on port 1883, which is acceptable only on a development LAN.

One setting is still open and must be changed before this stack serves real users:

• --without-auth: the InfluxDB API accepts any request, including deletes. Its port is bound to 127.0.0.1, so only processes on the VM reach it. Remove the flag and issue an admin token.
