BM Speed Cameras - QB/QBox Speed Cameras with Fines, Detection Logic, and Plate Notifications

A lightweight, configurable, and performance‑friendly speed camera system for FiveM (QBCore/QBox).

This script adds fully functional speed cameras to your server, complete with configurable speed limits, fines, directional detection, dual‑direction support, blips, props, and clean player notifications.

---

📌 Features Overview

• Speed Detection (MPH or KMH)
• Directional & Dual‑Direction Cameras
• Dynamic Fine System (base fine, % over limit, multipliers)
• Job Exemptions (police, EMS, etc.)
• Optional Blips for each camera
• Camera Props with ground alignment
• Flash & Sound Effects when triggered
• Debug Mode for camera placement
• Clean Notifications including the vehicle’s plate
• Fully Configurable through config.lua

---

📥 Installation

1. Place the resource folder into your server’s resources directory.
2. Add this to your server.cfg:

ensure bm-speedcameras

3. Configure everything in config.lua.

⚙️ Configuration Overview

All settings for the script are controlled through config.lua.
Every camera, fine, blip, and effect can be customized without touching the core code.

---

🔧 General Settings

Setting	Description
Locale	Language for notifications (currently only en)
DebugMode	Shows debug spheres for camera zones
UseMPH	Toggle between MPH (true) or KMH (false)

---

🔔 Notification Settings

Setting	Description
NotifyPosition	Screen position of notifications
NotifyDuration	How long notifications stay visible (ms)

---

🗺️ Blip Settings

Setting	Description
EnableBlips	Enable/disable all camera blips
DefaultBlipSprite	Default blip icon
DefaultBlipColour	Default blip colour
DefaultBlipScale	Default blip size
DefaultBlipLabel	Default blip name
DefaultShortRange	Only show blip when nearby
DefaultShortRangeDistance	Distance threshold for short‑range blips

---

💸 Fine System

Setting	Description
DefaultBaseFine	Base fine amount
DefaultFinePerPercent	Fine per 1% over the limit
DefaultMaxFine	Maximum fine allowed
DefaultPaymentType	cash or bank
FineMultiplier	Global multiplier for all fines

---

🚗 Vehicle Class Multipliers

Each GTA vehicle class can have its own multiplier.
Example: Motorcycles cheaper, emergency vehicles more expensive.

Config.VehicleClassMultiplier = {
    [0] = 1.0,   -- Compacts
    [1] = 1.0,   -- Sedans
    [2] = 1.2,   -- SUVs
    [8] = 0.7,   -- Motorcycles
    [18] = 1.5,  -- Emergency
}

🌙 Time‑of‑Day Multipliers

Config.TimeOfDayMultiplier = {
    day = 1.0,    -- 06:00–20:00
    night = 0.8   -- 20:00–06:00
}

🚫 Job Exemptions

Jobs listed here will never receive fines:

Config.ExcludedJobs = {
    police = true,
    ambulance = true,
    bcso = true,
    sahp = true
}

⚡ Flash & Sound Effects

These effects play when a player triggers a speed camera.

Setting	Description
FlashEnabled	Enables a bright screen flash when the camera triggers
FlashIntensity	Brightness of the flash effect
FlashDuration	Duration of the flash (in ms)
SoundEnabled	Plays a camera shutter sound when triggered

Example:

Config.FlashEnabled = true
Config.FlashIntensity = 1.0
Config.FlashDuration = 300
Config.SoundEnabled = true

🏗️ Camera Props

Each camera can optionally spawn a physical prop (e.g., CCTV pole).

• Props auto‑align to the ground
• Custom heading supported
• Optional Z offset for fine‑tuning

Example:

model = 'prop_cctv_pole_03',
heading = 245.0,
zOffset = -0.05,

If model = nil, no prop will spawn.

🧪 Debug Mode

Debug mode draws a visible sphere around each camera zone using ox_lib.

Config.DebugMode = true

Useful for:

• Testing camera placement
• Checking radius coverage
• Ensuring directional detection is correct

📸 Camera Definitions

Each camera is defined inside Config.SpeedCameras.

{
    coords = vec3(88.85, -1038.7, 29.46),
    radius = 20.0,
    speedLimit = 40,

    -- Optional prop
    model = 'prop_cctv_pole_03',
    heading = 245.0,
    zOffset = -0.05,

    -- Optional directional detection
    direction = 180.0,
    fov = 45.0,

    -- Optional dual-direction detection
    dual = true,
    dualFov = 45.0,

    -- Fine settings
    baseFine = 200,
    finePerPercent = 5,
    maxFine = 1000,
    paymentType = 'cash',

    -- Blip settings
    blip = {
        enabled = true,
        sprite = 744,
        colour = 0,
        scale = 0.6,
        label = "Speed Camera",
        shortRange = true,
        shortRangeDistance = 500.0
    }
}

🚦 How Speed Cameras Work

1. Player enters a camera radius

2. Script checks:

   • Speed
   • Speed limit
   • Direction (if enabled)
   • Dual‑direction (if enabled)

3. If speeding:

   • Fine is calculated
   • Multipliers applied
   • Money removed
   • Notification shown
   • Plate included in the message

4. A cooldown prevents repeated fines

🔔 Notification Example

You were caught speeding doing 60 in a 40 zone.
Fine: $300
Plate: EXAMPLE1

🛠 Dependencies

• ox_lib (notifications, debug zones)
• QBCore / QBox (player money, job data)

❓ Troubleshooting

• Enable DebugMode = true to visualize camera zones
• Check server console for config validation errors
• Ensure ox_lib is started before this resource
• Verify camera coordinates and radius values
• Ensure your blip settings are valid

License

You may use and edit this script for personal or server use.

If you reupload, redistribute, or share this script in any form, attribution is required.
You must credit the original author: BM Scripts.

You may not claim this script as your own.
